WINDOW AC
In Stock — Waipahu Warehouse
LG 7,600 BTU (LW8023HRSM)
$650
High-efficiency R32 cooling calibrated for Oahu residential circuits
Performance
7,600 BTU
10.9 CEERDual Sizing
Up to 320 sq. ft. (AHAM)
Up to 260 sq. ft. (Island)
Electrical Circuit
115V / 15 Amp (6.3 A (Cool) / 11.0 A (Heat))
NEMA 5-15P (Standard 115V / 15A)Window Opening Fit
Min 14" H
27"–39" Width SpanPre-Purchase Fit ChecklistRecommended Compatibility
1. Window Opening Clearance:Requires minimum 14" vertical height and 27" to 39" width span. Compatible with jalousies, sliders, and double-hung frames.
2. Electrical Outlet Matching:Powered by 115V / 15 Amp using NEMA 5-15P (Standard 115V / 15A). Verify your wall outlet receptacle before ordering.
3. Chassis Handling & Safety:Slide In-Out (Wall/Window) chassis architecture (66 lbs net). Outer mounting sleeve installs into window first for secure handling.
Unit Dimensions13.9" H x 18.4" W x 20.9" D
Weight (Net / Ship)66 lbs / 74 lbs
Manufacturer Warranty1 Year Limited
Dehumidification2.1 Pts/Hr
Amps / Watts6.3 A (Cool) / 11.0 A (Heat) / 670 W (Cool) / 1260 W (Heat)
Airflow / Sound220 CFM • Balanced Acoustics (50 / 52 dB)
Free Waipahu Warehouse Pickup$50 Flat Island Delivery
Request $0 In-Home Fit Assessment & InstallationZero Upfront Deposit • Hawaii CT-36775 Licensed Installation
By Appointment First • Free Estimates ($0 to Book)
Free Sizing EstimatePrefer to verify your room sizing, electrical compatibility (115V vs 230V), or installation requirements before purchasing? It is zero cost to book an appointment for estimates on new or replacement installations! Call us, email us, or submit the form below to reserve your appointment window.
Waipahu Warehouse Pickup by Appt
$50 Flat Island-Wide Delivery
$45 Hawaii Energy Rebate Form(PDF)Zero Upfront Estimate Fee
Manufacturer Warranty Coverage
All systems are brand new and factory-sealed.
Under federal regulations, all sales are final. Technical warranty claims are fully backed and processed directly through the manufacturer.
